CML2

The CML2 is a portable, accurate laser particle analyser suitable for ‘on-site’ applications. It can automatically measure and display particulate contamination, moisture and temperature levels in various hydraulic fluids.

RECALIBRATION SERVICE   TECHNICAL BROCHURE
  • FEATURES & BENEFITS
  • TECHNICAL DATA
  • LITERATURE
  • SOFTWARE
• Compact, lightweight and rugged Calibrated to relevant ISO standards
• Compatible with various hydraulic fluids
• FREE Windows based LPA View software
• Accessories kit included
• Measures and displays the following international standard formats; ISO 4406:1999,
  NAS 1638, SAE AS 4059 revision E tables 1 & 2
• Data logging and 600 test result memory
• Manual and remote control flexibility
• Internal rechargeable battery
Particle sizing
>4, 6, 14, 21, 25, 38, 50, 70 μm(c) to ISO 4406:2017
Standard analysis range
ISO 4406:2017 Code 8 to 24
NAS 1638 Class 2 to 12
AS4059 Rev. E Table 1 Size Codes 2-12 AS4059 rev E, Table 2 Size Codes, A:000 to 12, B:00 to 12, C:00 to 12, D:2 to 12, E: 4 to 12,F: 7 to 12
Accuracy
Better than 3% typical
Viscosity
Range Up to 400 cSt
Fluid temperature
From +5 °C to +80 °C
Ambient temperature
From -10 °C to +60 °C
Temperature measurement
±3 °C
Pressure
Minimum: 2 bar
Maximum: 400 bar
Sample volume / test time
8 ml. (short): 2:50 15 ml. (normal): 5:00 30 ml. (dynamic): 10:00 24 ml. (bottle sampler): 8:00 15 ml. (continuous): 5:00
BROCHURES
Contamination Control Solutions brochure
Product range brochure
CATALOGUES
Contamination Control Solutions Catalogue
CML2 compact portable APC
CMP Automatic Particle Counters
MANUALS
Use and maintenance manual for CML2
Use and maintenance manual for LPA View Software
LPA View: 5.101
